Laboratory techniques and equipment

guion

Portable and non-destructive techniques (or moderately destructive)

guion

Accessory material and equipments

The extent of Quality Management System implemented in the laboratory, includes the following geomaterials tests: testing water absorption at atmospheric pressure and vacuum (saturation), bulk and apparent density, open and total porosity, surface roughness, mercury intrusion porosimetry, ultrasonic propagation velocity, color measurement by spectrophotometer, contact angle, water vapour permeability, mineralogy, petrography and ion chromatography.


dynamic-analyzer

Analyzer dynamic
contact angle DCA-312;
Cahn Instruments

static-analyzer

Static analyzer contact angle
Phoenix 300 Seo; Surface Electro Optics

carbonation

Carbonation and sulfation climatic
chamber; Dicometal

chromatograph

Chromatograph 761
Compact Ic; Metrohm


microdurometer

Microdurometer
Thv-501E; Ibertest

microscope

Petrographic microscope; Jenapol

porosimeter

Porosimeter
Micromeritics
Autopore Iv 9520;
Micromeritic

profilometer

Profilometer Sj-201; Mitutoyo


acuasor-system

Acuasor System for
determining the properties
of water in porous systems

ultrasound-propagation

Equipment of ultrasound propagation
speed measurement Pr 5058
(Pulser Receiver);
Panametrics Ntd

adhesion-tester

Adhesion Tester
Dyna 26; Proceq
(destructive technique)


glossmeter

Glossmeter Minolta 268 Multigloss;
BYK Gardner

thermacam-infrared

B4 Thermacam infrared
camera;
Flir Systems

infrared-camera

Infrared video camera;
Optris PI

conductivimeter

Conductivimeter HD2156.2 Datalogger;
CRN Tecnopart, S.A.


drilling

Drilling Resistance Measuring System;
Sint Technology

endoscope

Endoscope Light Scope;
Moritex Corporation

equipment-fluorescence

Equipment of X-Ray
Fluorescence Niton; Panreac

ultrasound-propagation

Equipment of ultrasound propagation
speed measurement Pundit;
Cns Electronics


ultrasound-propagation

Equipment of ultrasound propagation
speed measurement Pr 5058
(Pulser Receiver);
Panametrics Ntd

equipment-geoelectrical

Equipment of high-resolution
geoelectrical survey Geotom;
Geolog2000

test-hammer

Test hammer 2000 Dig-Schmidt
Nd; Proceq

spectrophotometer

Spectrophotometer
Cm 700d; Minolta


magnetometer

Magnetometer Profotometer 4; Proceq

moisturemeter

Moisturemeter
Protimeter Surveymaster;
General Electric

microdurometer

Rebound microdurometer
Leeb Equotip 3D; Proceq

oscilloscope

Oscilloscope Tds3012b;
Tektronics


Permeameter

Permeameter Tiny-Perm-II;
Vindum Engineeering

temperature-logger

Temperature logger
Sq 800;
Squirrel/Grant

optical-profilometer

Optical profilometer TRACEiT; Innowep

termohigrometers

Termohigrometers Hi 8564
from Hanna Instruments
and 601 from Testo


smartmote

Smartmote wireless
system; Smartmote

co2-temperature-probe

CO2 and temperature probe;
Telaire®7001; General Electric

infrared-thermometer

Infrared
thermometer; Neurtek


tube-agitator

Tube agitator Reax
Contrl; Heidolph

balances

Balances: Cp324s,
Sartorius,
Fx-1200i, A&D

ultrasonic-bath

Ultrasonic bath
Ultrasons-H; Selecta

vacuum-chamber

Vacuum chamber to test on rocks
Rc-002; Test Systems, S.L


Centrifuge-thermo

Centrifuge Thermo
Labofuge 400; Heraeus

ultrasonic-divisive

Ultrasonic divisive
Labsonic 2000; B.Braun

stoves

Stoves: Ulm 400;
Ulm 500 Memmert

micromotor

Micromotor Art 6000; CTS


muffle

Muffle CWF 1200; Carbolite

phmeter

Stone Phmeter 826 Ph
Mobile - 827 Ph Lab; Metrohm

pulverizer

Pulverizer Pulverisette;
Fritzsch

water-purifier

Water purifier
System Direct Q©3;
Millipore


digital-telemeter

Digital telemeter

drillings

Drillings: Diamant Board,
Bs 45 Bosh
